SPECS
GENERAL
-
Copier Typedigital
-
Printing TechnologyLaser – monochrome
-
Monthly Duty Cycle (max)300000 impressions
-
Office Machine FeaturesXerox Extensible Interface Platform (EIP), scan to e-mail, scan to folder, scan to network
-
Display FeaturesTouch screen
-
Electronic Auditron2500 accounts
-
ManufacturerXerox
MEMORY
-
Standard Memory1 GB
-
Max Supported Memory2 GB
-
Hard Disk Drive80 GB
PRINTER
-
First Print Out Time B/W2.7 sec
DISPLAY
-
Featurestouch screen
MISCELLANEOUS
-
Consumables Included1 x cartridge (black) – up to 30000 pages
-
Compliant StandardsCB, DOC, EN 60950, FCC Class A certified, IEC 60950, UL 1950 Third Edition
-
First Copy Out Time B/W2.7 sec
POWER
-
Power Consumption Sleep15 Watt
-
Power Consumption Standby320 Watt
-
Power Consumption Operational1690 Watt
COPYING
-
Max Copying SpeedUp to 75 ppm
-
Max Copying ResolutionUp to 600 x 4800 dpi
-
Max Copying Speed B/W75 ppm
-
Max Copying Resolution B/W600 x 4800 dpi
-
Warm-Up Time30 sec
-
First Copy Out Time B/W2.7 sec
-
Max Document Enlargement400 %
-
Max Document Reduction25 %
-
Automatic DuplexingYes
-
Maximum Copies9999
-
Exposure Modesphoto, text, text and photo
-
Copying FeaturesID Card Copy, Preset Reduction/Enlargement Ratios, auto paper select, auto tray switching
RAM
-
Installed Size1 GB
-
Max Supported Size2 GB
ENVIRONMENTAL STANDARDS
-
Blue Angel CompliantYes
-
ENERGY STAR CertifiedYes
PRINTING
-
Max Printing ResolutionUp to 1200 x 1200 dpi
-
Max Printing SpeedUp to 75 ppm
-
Max Resolution B/W1200 x 1200 dpi
-
Printer Drivers / EmulationsPCL 5e, PCL 6, PDF, PostScript 3
-
Max Printing Speed B/W (ppm)75 ppm
-
Automatic DuplexingYes
FINISHING EQUIPMENT
-
Stackeroptional
-
Stapleroptional
-
Binderoptional
CONNECTIONS
-
Interfaces1 x USB
1 x Gigabit LAN -
Network ProtocolsAppleTalk, IPP, IPX/SPX, LPR/LPD, NetBEUI, RAW IP (Port 9100), SMB, TCP/IP
-
Security Protocols & FeaturesKerberos, LDAP, Secure Print, SSL, Apple Bonjour, SMB authentication, IPsec, 802.1x, Secure Fax
-
Operating System SupportMS Windows XP, Novell NetWare 5.x, MS Windows Server 2003, Sun Solaris 8, Sun Solaris 9, Apple Mac OS X 10.4, Apple Mac OS X 10.5, MS Windows 7, Apple Mac OS X 10.6.x, openSUSE 11.0, MS Windows Vista, Red Hat Enterprise Linux 4, HP-UX 11i v2, Sun Solaris 10, Fedora Linux, MS Windows Server 2008, Novell NetWare 6.x, IBM AIX 5.3, SunSoft Solaris x86 10
ENVIRONMENTAL PARAMETERS
-
Min Operating Temperature50 °F
-
Max Operating Temperature89.6 °F
-
Humidity Range Operating10 – 85%
DOCUMENT & MEDIA HANDLING
-
Max Media SizeA3
-
Document & Media Handling DetailsADF – 100 sheets size: A5 (5.83 in x 8.25 in) – A3 (11.7 in x 16.5 in) weight: 50 g/m² – 160 g/m²
Bypass tray – 100 sheets size: A6 (4.13 in x 5.83 in) – A3 (11.7 in x 16.5 in) weight: 60 g/m² – 216 g/m²
2 x input tray – 500 sheets size: A5 (5.83 in x 8.25 in) – A3 (11.7 in x 16.5 in) weight: 60 g/m² – 200 g/m²
Input tray – 1600 sheets – A4 (8.25 in x 11.7 in) weight: 60 g/m² – 200 g/m²
Input tray – 2000 sheets – A4 (8.25 in x 11.7 in) weight: 60 g/m² – 200 g/m² -
Speed DetailsCopying: up to 75 ppm (A4)
Copying: up to 42 ppm (A3)
Printing: up to 75 ppm (A4)
Printing: up to 42 ppm (A3)
Scanning: up to 80 ppm (A4) – B/W -
Min Original SizeA6 (4.13 in x 5.83 in)
-
Max Original SizeA3 (11.7 in x 16.5 in)
-
Original Typebooks, sheets
-
Document FeederADF
-
Document Feeder Capacity100 sheets
-
Media Type Classenvelopes, film / transparencies, other, plain paper
-
Media Size ClassA3
-
Min Media SizeA6 (4.13 in x 5.83 in)
-
Min Media Weight60 g/m²
-
Max Media Weight216 g/m²
-
Supported Media Typebond paper, envelopes, labels, plain paper, recycled paper, transparencies
-
Supported Media SizesA3 (11.7 in x 16.5 in), A4 (8.25 in x 11.7 in), A5 (5.83 in x 8.25 in), A6 (4.13 in x 5.83 in)
-
Standard Media Capacity4700 sheets
-
Max Media Capacity8700 sheets
-
Bypass Feeder Capacity100 sheets
HEADER
-
BrandXerox
-
Product LineXerox WorkCentre
-
Model5775
-
Bundled withHigh-Capacity Tandem Tray
-
Packaged Quantity1
INTERFACE REQUIRED
-
TypeGigabit LAN, USB
-
Total Qty1
OFFICE MACHINE
-
Typeprinter / copier / scanner
-
Functionscopier, printer, scanner
-
Monthly Duty Cycle (max)300000 impressions
-
Printing Technologylaser
-
Printing Output Typemonochrome
-
Electronic Auditron2500 accounts
-
Office Machine FeaturesXerox Extensible Interface Platform (EIP), scan to e-mail, scan to folder, scan to network
DIMENSIONS & WEIGHT
-
Width37.6 in
-
Depth27.7 in
-
Height45.3 in
SCANNING
-
Optical Resolution600 x 600 dpi
PRINTING SYSTEM
-
First Print Out Time B/W2.7 sec
CONSUMABLES INCLUDED
-
Typecartridge
-
Duty Cycle30000 pages
-
Colorblack
-
Included Qty1
DOCUMENT & MEDIA HANDLING DETAILS
-
TypeADF, bypass tray, input tray
-
Media Feeder Qty2
-
Media Feeder Capacity100 sheets, 1600 sheets, 2000 sheets, 500 sheets
-
Min Media Weight50 g/m², 60 g/m²
-
Max Media Weight160 g/m², 200 g/m², 216 g/m²
-
Min Media SizeA5 (5.83 in x 8.25 in), A6 (4.13 in x 5.83 in)
-
Max Media SizeA3 (11.7 in x 16.5 in), A4 (8.25 in x 11.7 in)
SOFTWARE
-
Operating System SupportApple Mac OS X 10.4, Fedora Linux, HP-UX 11i v2, IBM AIX 5.3, MS Windows 7, MS Windows Server 2003, MS Windows Server 2008, MS Windows Vista, MS Windows XP, Novell NetWare 5.x, Novell NetWare 6.x, Red Hat Enterprise Linux 4, Sun Solaris 10, Sun Solaris 8, Sun Solaris 9, SunSoft Solaris x86 10, openSUSE 11.0
SPEED DETAILS
-
Functioncopying, printing, scanning
-
Max Speed42 ppm, 75 ppm, 80 ppm
-
SizeA3, A4
-
ModeB/W
PC CONNECTIVITY
-
Connection AvailabilityYes
-
InterfaceGigabit LAN, USB
-
Security Protocols & Features802.1x, Apple Bonjour, IPsec, Kerberos, LDAP, SMB authentication, SSL, Secure Fax, Secure Print
POWER ADAPTER
-
Voltage RequiredAC 230 V
-
Frequency Required50/60 Hz
-
Power Consumption Operational1690 Watt
-
Power Consumption Standby320 Watt
-
Power Consumption Sleep15 Watt
GENERAL
-
ManufacturerXerox
