COPIER
|
|
| Copying process |
Single laser beam scanning & electro-photographic printing |
|
| Copy speed |
23 copies per minute |
|
| Resolution |
600 dpi |
|
| Warm-up time |
Less than 20 seconds |
|
| First output speed |
5.4 seconds |
|
| Memory |
Maximum |
1 GB + 120 GB HDD |
|
| Paper input capacity |
Maximum |
3,150 sheets |
|
| Paper output capacity |
Maximum |
1,625 sheets |
|
| Paper size |
A6 – A3 |
|
| Paper weight |
Paper tray |
52 – 157 g/m² |
|
|
|
Bypass tray |
52 – 157 g/m² |
|
|
|
Duplex tray |
52 – 105 g/m² |
|
| Dimensions (W x D x H) |
587 x 653 x 829 mm (with ARDF) |
|
| Weight |
Less than 65 kg (less than 75 kg with ARDF) |
|
| Power source |
220 – 240 V, 50/60 Hz |
|
| Power consumption |
Maximum |
Less than 1.6 kW |
|
PRINTER
|
|
| Print speed |
23 prints per minute |
|
| Printer language |
Standard |
PCL5e |
|
|
|
|
|
PCL6 |
|
|
|
|
|
Adobe PDF Direct |
|
|
|
Option |
Adobe® PostScript® 3™ |
|
|
|
|
|
IPDS |
|
| Resolution |
Maximum 600 x 600 dpi |
|
| Interface |
Standard |
USB 2.0 |
|
|
|
|
|
Ethernet 10 base-T/100 base-TX |
|
|
|
Option |
IEEE 1284/ECP |
|
|
|
|
|
Wireless LAN (IEEE 802.11a/b/g) |
|
|
|
|
|
Bluetooth |
|
|
|
|
|
Gigabit Ethernet |
|
| Network protocol |
TCP/IP (IPv4, IPv6) |
|
|
|
IPX/SPX |
|
| Supported environments |
Windows® XP/Vista/7/Server 2003/Server 2008 |
|
|
|
Novell® NetWare® 6.5 or later |
|
|
|
UNIX Sun® Solaris 2.6/7/8/9/10 |
|
|
|
HP-UX 10.x/11.x/11iv2/11iv3 |
|
|
|
SCO OpenServer 5.0.6/5.0.7/6.0 |
|
|
|
RedHat® Linux 6.x/7.x/8.x/9.x/Enterprise |
|
|
|
IBM® AIX v4.3/5L v5.1/5.2/5.3 |
|
|
|
Macintosh X v10.2 or later |
|
|
|
NDPS Gateway Netware 6.5 (SP3 or later) |
|
|
|
IBM iSeries/AS400 using OS/400 Host Print Transform |
|
|
|
Citrix Presentation Server 4.5/Citrix XenApp 5.0 |
|
SCANNER
|
|
| Scan speed |
Full colour |
Maximum 45 ipm |
|
|
|
B/W |
Maximum 50 ipm |
|
| Resolution |
Maximum 600 dpi |
|
| Original size |
A5 – A3 |
|
| Bundled drivers |
Network TWAIN |
|
| Scan to e-mail |
SMTP |
|
|
|
TCP/IP |
|
| Scan to folder |
SMB |
|
|
|
FTP |
|
|
|
NCP protocol (with login security) |
|
SOFTWARE SOLUTIONS
|
|
- SmartDeviceMonitor™
- Web SmartDeviceMonitor™
- Web Image Monitor
|
|
FAX (OPTION)
|
|
| Circuit |
PSTN |
|
|
|
PBX |
|
| Compatibility |
ITU-T (CCITT) G3 |
|
|
|
ITU-T (T.37) Internet Fax |
|
|
|
ITU-T (T-38) IP Fax |
|
| Modem speed |
Maximum |
33.6 Kbps |
|
| Scanning speed |
0.5 seconds (A4/SEF/standard mode) |
|
| Memory capacity |
4 MB standard, 36 MB max. |
|
| Memory backup |
Yes |
|
OTHER OPTIONS
|
|
- 50-sheet ARDF1
- Platen cover1
- 1 x 550-sheet paper tray
- 2 x 550-sheet paper trays
- 2,000-sheet LCT
- One-bin tray
- Internal shift tray
- 500-sheet internal finisher
- 500-sheet external finisher
- 1,000-sheet finisher
- 1,000-sheet booklet finisher
- Punch kits
- Bridge unit
- Hard Disk Drive option1
- Memory unit1
- Printer/scanner unit1
- Printer unit1
- Scanner enhance option1
- PostScript 3 unit
- IPDS unit
- VM card1
- USB2.0/SD slot
- Fax option
- G3 interface unit
- Memory unit for fax
- Bluetooth interface
- IEEE 802.11 a/g interface
- Gigabit Ethernet board
- IEEE 1284 interface board
- Unicode font package
- File format converter
- Browser unit
- Caster table
- Card reader bracket
- Accessibility handle
- Counter interface unit
- Key counter bracket
- Professional software solutions
|
