| Configuration |
|
Console |
|
| Printing Process |
|
Single Laser Beam Scanning & Electrophotographic printing |
|
| Dimensions (W x D x H) |
|
24.8″(W) x 25.7″(D) x 27.9″(H) |
|
| Weight |
|
143 lbs. |
|
| Standard Paper Capacity |
|
500 sheets x 2 trays and 100-sheet bypass tray |
|
| Optional Paper Capacity |
|
500 sheets x 2 trays or 2000 sheet large capacity tray (LCT) |
|
| Paper Size |
|
5.5″ x 8.5″ to 11″ x 17″/ A6 to A3 |
|
| Paper Weight |
|
16 – 28 lb. Bond/60 – 105g/m² (Tray 1 and Duplex)
14 – 42 lb. Bond/52 – 157g/m² (Tray 2 and Bypass) |
|
| Reduction Ratios |
|
25%, 50%, 65%, 73%, 78%, 85%, 93%, 100% |
|
| Enlargement Ratios |
|
121%, 129%, 155%, 200%, 400% |
|
| Zoom |
|
25% to 400% in 1% increments |
|
| Standard Features |
|
Auto Magnification, Auto Paper Select, Auto Tray Switch, Center/Border Erase, Chapters, Full-Color VGA Touch Screen Control Panel, Combine Mode, Cover Insertion, Date Stamp, Directional Magnification, Electronic/Rotate Sorting, English Pre-Set Stamps, Negative/ Positive, OHP Slip Sheet, Page Number Stamp, 10 Job Programs, 500 User Codes |
|
| Document Feeding |
|
Optional 50-sheet ARDF |
|
| Optional Features with HDD |
|
Background Numbering, Booklet/Magazine Copy, Document Server (3000 file capacity) and User stamps |
|
| Security Features |
|
S/MIME, IPsec Communication, Locked Print Password Encryption, Encrypt Address Book, SSL Secure Socket Layer, User Authentication, SNMP v3, Encryption of Password PDF, Encrypted PDF |
|
| Toner |
|
Dry, Dual Component |
|
| System Memory (std/max.) |
|
256/512 MB RAM |
|
| Hard Disk Drive |
|
40 GB optional |
|
| Copy Resolution |
|
600 x 600 dpi |
|
| Grayscale |
|
256 levels |
|
| Exposure Adjustment |
|
Manual & Automatic |
|
| Scanning Element |
|
Flatbed with Moving CCD Array Image Sensor |
|
| Quantity Indicator |
|
Up to 999 |
|
| Original Type |
|
Book/Sheet |
|
| Maximum Original Size |
|
Up to 11″ x 17″ |
|
| Copy Size |
|
5.5″ x 8.5″ to 11″ x 17″ |
|
| Copy Type |
|
Plain Paper, Transparencies, Envelopes, Cardstock, Recycled |
|
| Warm-Up Time |
|
14 seconds |
|
| First Copy Speed |
|
4.5 seconds |
|
| Continuous Copying Speed |
|
25 copies/minute (LTR) |
|
| Recovery Time |
|
10 seconds (from Auto Off) |
|
| Power Source |
|
120V/60Hz/12A |
|
