| BASIC SPECIFICATIONS |
| Type |
Desktop or Free-standing, (Reader-Printer Combined) |
| Maximum Original Size |
A3 |
| Copy Sizes |
Cassette 1,3 and 4: A3, A4, A4R, A5R
Custom size: 139.7 to 297mm x 182 to 432mm
Cassette 2: A3, A4, A4R, A5R,
Stack Bypass: A3, A4, A4R, A5R,
Custom size: 99 to 297mm x 148 to 432 mm |
| Resolution |
Reading: 600dpi × 600dpi
Copying: 600dpi × 600dpi
Printing: 600dpi × 600dpi, 1200dpi x 1200dpi (UFRll-LT only)
Number of Tones: 256 Gradations |
| Copy/Print Speed |
A4:
imageRUNNER 2545i/2545 : 45ppm (BW)
imageRUNNER 2535i/2535 : 35ppm (BW)
imageRUNNER 2530i/2530 : 30ppm (BW)
imageRUNNER 2525i/2525 : 25ppm (BW)
imageRUNNER 2520i/2520 : 20ppm (BW)
A3:
imageRUNNER 2545i/2545 : 22ppm (BW)
imageRUNNER 2535i/2535 : 22ppm (BW)
imageRUNNER 2530i/2530 : 15ppm (BW)
imageRUNNER 2525i/2525 : 15ppm (BW)
imageRUNNER 2520i/2520 : 15ppm (BW) |
| Enlargement/ Reduction |
Zoom: 25-400%
Fixed: 25%, 50%, 70%, 100%, 141%, 200%, 400% |
| First copy time |
Black-and-White: 3.9sec (45/35 ppm model), 5.4sec (30/25 ppm model), 6.4sec (20 ppm model) |
| Warm-Up Time |
30 seconds |
| Multiple Copies/Prints |
1 to 999 sheets |
| Duplexing |
Standard |
| Paper weight |
Cassette: 64 to 90g/m2
Stack Bypass: 64 to 128g/m2
Duplex: 64 to 80g/m2 |
| Paper Capacity |
Cassette 1: 550 sheets (80g/m2), (250 sheets for the imageRUNNER 2520i/ 2520)
Cassette 2: 550 sheets for imageRUNNER 2525/i, 2530/i, 2535/i, 2545/i.
Stack Bypass: 100 sheets (A4,A4R,A5;80g/m2), 50 sheets(A3;80g/m2)
Optional:
550 sheets x 2 cassettes (80g/m2)
550 sheets x 1 cassette for imageRUNNER 2520/2520i only
Paper Deck: None
Total capacity: 2,300 sheets,(2,000 sheets for the imageRUNNER 2520i/ 2520) |
| Processor speed |
Canon Custom Processor, 400MHz |
| Memory |
512MB (imageRUNNER 2500 i models), 256MB (imageRUNNER 2500 non i models) |
| Hard Disk Drive |
None |
| Interface |
Ethernet (100Base-TX/10Base-T), USB Host I/F 2.0 x 1 port, USB Device 1.0 x 1 port
220-240V AC, 50/60Hz, 4.2A (45/35 ppm model), 220-240V AC, 50/60Hz, 3.3A (35/30/20 ppm model) |
| Power Supply |
220-240V AC, 50/60Hz, 4.2A (45/35 ppm model), 220-240V AC, 50/60Hz, 3.3A (35/30/20 ppm model) |
| Power Consumption |
1.827kW (45/35ppm model), 1.345kW (30/25ppm), 1.542kW (20ppm model) |
| Dimensions (W x D x H) |
imageRUNNER 2545i/ 2545/ 2535i/ 2535 :
565 mm x 680 mm x 806 mm (with the platen cover)
565 mm x 689 mm x 907mm (with the DADF)
imageRUNNER 2530i/ 2530/ 2525i/ 2525 :
565 mm x 680 mm x 806 mm (with the platen cover)
565 mm x 689 mm x 896 mm (with the DADF)
imageRUNNER 2520i/ 2520 :
565 mm x 680 mm x 681 mm (with the platen cover)
565 mm x 689 mm x 771 mm (with the DADF) |
| Weight |
imageRUNNER 2545i/2535i :
Approx. 78.4 kg, imageRUNNER 2545/2535: Approx. 70.5 kg
imageRUNNER 2530i/2525i :
Approx. 77.5 kg, imageRUNNER 2530/2525: Approx. 68.0 kg
imageRUNNER 2520i :
Approx. 56.0 kg, imageRUNNER 2520: Approx. 50.5 kg |
|
| NETWORK PRINTER KIT SPECIFICATIONS |
| PDL |
UFRII-LT, PCL5e/6 (standard on i models, optional on non i models), PostScript level 3 emulation (optional) |
| Resolution |
600 x 600dpi, 1200dpi x 1200dpi (UFRll-LT only) |
| Memory |
512MB (imageRUNNER 2500 series i models), 256MB (imageRUNNER 2500 series non i models) |
| Hard Disk |
None |
| CPU |
Canon Custom Processor, 400MHz |
| PS Fonts |
Roman 136 |
| PCL Fonts |
Roman 93 |
| Supported OS |
PCL: Windows 2000/ XP/ Server 2003/ Vista/ Server 2008/ Windows 7
Postscript level 3 emulation: Windows 2000/ XP/ Server 2003/ Vista/ Server 2008/ Windows 7, Mac OS X (10.4 or later)
UFRII-LT: Windows 2000/ XP/ Server 2003/ Vista/ Server 2008/ Windows 7, Mac OS X (10.4 or later), Linux
Mac-PPD: Mac OS X 10.4 or later |
| Interface |
Ethernet (100Base-TX/10Base-T) |
| Network Protocol |
TCP/IP(LPD/ Port9100, HTTP), SMB, SNMP v1, WSD, IPv4/ IPv6 support |
| Pull Scan |
Network TWAIN Driver (75/ 100/ 150/ 200/ 300dpi 8bit color / 75-600dpi 1bit Black & white) |
|
| UNIVERSAL SEND KIT SPECIFICATIONS |
| Optional/Standard |
CLR SEND KIT-Y1 (standard on i models, optional on non i models) |
| Scan Speed |
A4, 300dpi, BW/Color: 45/34 ipm (45/ 35 ppm model), 25/13ipm( 30/ 25/ 20 ppm model) |
| Scan Resolution |
BW: 100 x 100 dpi, 150 x 150 dpi, 200 x 100dpi, 200 x 200 dpi, 200 x 400 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi
CL:100 x 100 dpi,150 x 150 dpi, 200 x 200 dpi, 300 x 300dpi |
| Destinations |
E-Mail/ Internet FAX(SMTP), PC/Server (SMB,FTP), iWDM, USB memory key |
| Address Book |
Local (Max. 500) |
| File Format |
TIFF, JPEG, PDF, High compression PDF |
|
| PDF HIGH COMPRESSION KIT |
| Model Name |
SEARCHABLE PDF-C1 |
| Format |
Searchable PDF (optional) |
|
| DADF SPECIFICATIONS |
| Optional/Standard |
DADF-AA1 for imageRUNNER 2545/2535
DADF-AB1 for imageRUNNER 2530/2525/2520 |
| Paper Size |
imageRUNNER 2545/2535: A3, A4, A4R, A5, A5R
imageRUNNER 2530/2525/2520: A3, A4, A4R, A5, A5R
Custom size 139.7 to 297mm x 182 to 432mm |
| Paper Weight |
imageRUNNER 2545/2535:
Single sided original: 42 to 128 g/m2
Double sided original: 50 to 128 g/m2
imageRUNNER 2530/2525/2520:
Single sided original: 37 to 128 g/m2
Double sided original: 50 to 128 g/m2 |
| Max no. of originals |
imageRUNNER 2545/2535:
100 sheets (A4, A4R, A5, A5R: 80 g/m2), 50 sheets (A3: 80 g/m2)
imageRUNNER 2530/2525/2520:
50 sheets (A4, A4R, A5, A5R: 80 g/m2), 25 sheets (A3: 80 g/m2) |
| Document Scanning Speed |
imageRUNNER 2545/2535:
Copy: 45ipm (A4, 600 x 600 dpi: BW )
Scan: 45/34 ipm (A4, 600 x 600 dpi: BW / 300 x 300 dpi: Colour)
imageRUNNER 2530/2525/2520:
Copy: 25ipm (A4, 600 x 600 dpi: BW )
Scan: 25/13 ipm (A4, 600 x 600 dpi:BW / 300 x 300 dpi: Colour ) |
| Dimensions |
imageRUNNER 2545/2535: 565 mm x 540 mm x 137 mm
imageRUNNER 2530/2525/2520: 565 mm x 544 mm x 126 mm |
| Weight |
imageRUNNER 2545/2535: Approx. 7.9 kg
imageRUNNER 2530/2525/2520: Approx. 7.0 kg |
|
| CASSETTE FEEDING MODULE SPECIFICATIONS |
| Model Name |
CASSETTE UNIT-W1 for imageRUNNER 2520/i
CST. Feeding UNIT-AE1 for all models |
| Type |
imageRUNNER 2520/i: Front-loading adjustable drawers
all models: 2 Front-loading adjustable drawers |
| Paper weight |
imageRUNNER 2520/i: 64 to 90g/m2
all models: 64 to 90 g/m2 |
| Paper Capacity |
imageRUNNER 2520/i: 550 sheets (80 g/m2) x 1 cassette
all models: 550 sheets(80 g/m2) x 2 cassettes |
| Dimensions |
imageRUNNER 2520/i: 565 mm x 680 mm x 97 mm
all models: 565 mm x 680 mm x 248 mm |
| Weight |
imageRUNNER 2520/i: Approx. 12.8kg
all models: Approx. 24.0kg |
|
| FINISHER SPECIFICATIONS |
| Optional/Standard |
Inner Finisher-B1 for all models |
| Number of Trays |
One stack tray (Optional 2nd Tray;INNER FIN ADD. TRAY-B1) |
| Tray Capacity |
A4 – A5R :1000 sheets (or 125 mm in height)
A3, A4R: 500 sheets (or 62.5 mm in height) |
| Staple Position |
Corner, Double |
| Staple Capacity |
A4: 50 sheets x 30 sets
A4R/ A3: 30 sheets x 15 sets |
|
| Inner 2 Way Tray SPECIFICATIONS |
| Tray Capacity |
Tray A – A4: 250 sheets, A3: 100 sheets
Tray B – A4:100 sheets, A3: 50 sheets |
| Weight |
Approx. 0.6kg |
|
| ADDITIONAL OPTIONAL ACCESSORIES |
| Additional options |
Platen Cover Type P: Platen cover to be selected when configuring imageRUNNER 2525/2530 without DADF
Platen Cover Type Q: Platen cover to be selected when configuring imageRUNNER 2535/2545 without DADF
Stamp Ink Cartridge-C1: Stamp Ink Cartridge
Stamp Unit-B: Stamp Unit
ADF Access Handle-A1:Attaches to the document feeder, making access easier for seated users
PCL Printer Kit-AF1: Supports PCL5e and PCL6 printing for non-i Models
PS Printer Kit-AF1: Supports PostScript Level 3 Emulation printing
Barcode Printing Kit-B1: Provides Barcode printing capability using Jet Caps technology
Super G3 Fax Board-AG1: Add fax functionality
FL Cassette-AJ1: This spare 550-sheet tray for cassette “1” of imageRUNNER 2525/2525i/2530/3530i/2535/2535i/2545/2545i
FL Cassette-AK1: This spare 550-sheet tray for cassette “2” of imageRUNNER 2525/2525i/2530/3530i/2535/2535i/2545/2545i or for Cassette Feeding Unit-AE1 or Cassette Module-W1 allows you to swap paper sizes without changing the printer settings
FL Cassette-AL1: This spare 250-sheet tray for cassette “1” of imageRUNNER 2520/2520i allows you to swap paper sizes without changing the printer settings
Cassette Spacer-A1: Adjusts the height for 250-sheet cassette when combined with optional Cassette Feeding Unit-AE1 or Cassette Module-W1 on imageRUNNER 2520/2520i only
imageRUNNER 2500 Plain Pedestal: The pedestal substitutes for the cassette feeding unit and raises the device,
2 Way Unit-B1: Enhances the double-sided print productivity up to 100%
Reversal Pass Unit(2-Way Unit) option for imageRUNNER 2520/2520i/2525/2530
Staple-J1:Staples for Inner Finisher-B1
Document Tray-J1: Handy tray that attaches to the side of the device and provides a location for placing originals
Power Supply Unit-U1: Power Supply Unit.
Card Reader Attachment-D3: Attachment kit for Card Reader-E1
Canon Card Reader-E1: Physical card access system that limits system access to authorised users
USB Application 3-Port Interface Kit-A1: 3-Port USB interface kit for USB memory
CCVI I/F Cable-A1: Interface Kit for Coin-Vender
C-EXV33 TONER BK: Toner for imageRUNNER 2520/2520i/2525/2525i/2530/2530i
C-EXV32 TONER BK: Toner for imageRUNNER 2535/2535i/2545/2545i |
|
