Copier:
Configuration | Desktop |
Scanning Element | One Dimension solid scanning through CCD |
Printing Process | Twin Laser Beam Scanning & Electrophotographic Printing |
Toner | Dry, Dual Component |
System Memory (RAM) (Min/Max) | 512 MB RAM/1 GB RAM + 128 GB HDD |
Hard Disk Drive | 128 GB (Optional) |
Document Feeder | 100-Sheet ARDF (Standard) |
Copy Resolution | 600 x 600 dpi |
Grayscale | 256 levels |
Exposure Adjustment | Manual & Automatic (Standard) |
Quantity Indicator | Up to 999 |
Original Type | Book/Sheet |
Maximum Original Size | Up to 11″ x 17″ |
Copy Size | 5.5″ x 8.5″ to 11″ x 17″ |
Copy Type | Plain Paper, Transparencies, Recycled Paper, Card Stock, Letterhead, Envelope |
Warm-Up Time | Less than 15 seconds |
First Copy Speed | 4.1 seconds |
Continuous Copying Speed | 40 copies/minute (LTR) |
Recovery from Sleep Mode | Less than 12 seconds |
Typical Energy Consumption (TEC) | 2.89kWh |
Power Source | 120V/60Hz, 12A |
Dimensions | 26.38″ (W) x 26.85″ (H) x 26.9″ (D) (670 x 682 x 682 mm) |
Weight | Less than 213.8 lbs. (97 kg) |
Standard Paper Capacity | 550 sheets x 2 trays 100-Sheet Bypass Tray |
Optional Paper Capacity | 550 sheets x 2 trays or 2,000 x 1; 1,200-Sheet Large Capacity Tray (LCT) |
Paper Size | Tray 1 & 2: 7.25″ x 10.5″ to 11″ x 17″ (Executive – A3); Bypass: 5.5″ x 8.5″ (SEF) to 11″ x 17″ (A5 – A3) |
Paper Weight | Tray 1 & 2: 16 – 57 lb. Bond/60 – 216 g/m² Bypass: 14 – 58 lb. Bond/52 – 220 g/m² Duplex: 16 – 44 lb. Bond/60 – 169 g/m² |
Reduction Ratios | 25%, 50%, 65%, 73%, 78%, 85%, 93% |
Enlargement Ratios | 121%, 129%, 155%, 200%, 400% |
Zoom | 25% to 400% in 1% increments |
Standard Features | Auto Magnification, Auto Paper Select, Auto Tray Switch, Center/Border Erase, Chapters, Combine Mode, Cover Insertion, Directional Magnification, Double Copy, Electronic/Rotate Sorting, Full-Color WVGA Touch Screen, 25 Job Programs, Negative/Positive, OHP Slip Sheet, Paper Designate, Sample Copy, Simple Screen, 1,000 User |
Requires Hard Disk Drive for Copier Basic Models | Document Server, Stamping on Copies |
Printer:
Print Speed | 50 ppm |
CPU | RM7035C-533 MHz |
Standard Interfaces | 10BaseT/100BaseTX, USB 2.0 |
Optional Interfaces | IEEE 802.11a/b/g Wireless LAN, Bluetooth, Gigabit Ethernet, IEEE 1284 |
Memory Capacity | Shared with Copier Memory |
Network Protocol | TCP/IP, IPX/SPX |
Network Operating Systems | Windows XP/Vista, Server 2003/Server 2008/Server 2008R2 and Windows 7, Netware Server 6.5**, UNIX; Sun Solaris, HP-UX, SCO OpenServer, RedHat Linux, IBM AIX, Mac OS, OS X 10.2 or later, SAP R/3, NDPS Gateway, IBM iSeries/AS/400 using OS/400 Host Print Transform |
Utilities | Web Image Monitor, Embedded @Remote |
Page Description Languages | Standard PCL 5e/6, PDF, Direct Print and Adobe® PostScript® 3™/IPDS (Optional) |
Print Resolution | Up to 600 dpi |
Fonts for PCL5e/6 | 45 Intellifonts, 13 International Fonts |
Fonts for PS3 | 136 Roman Fonts |
Standard Features | Sample/Locked/Hold/Stored Print/ |
Scanner:
Scanning Speed | BW: 61 ipm (@200 dpi, 8.5″ x 11″ LEF) FC: 31 ipm (@200 dpi) |
Scanning Resolution | Up to 600 dpi |
Grayscale | 256 levels |
Scan Area | Up to 11″ x 17″ |
Standard Interfaces | 10BaseT/100BaseTX Ethernet |
Optional Interfaces | Wireless LAN (802.11a/b/g), Gigabit Ethernet |
Protocol | TCP/IP, SMTP, SMB, FTP, POP3, NCP** |
**Requires Netware and Print/Scan Options
|
|
Memory Capacity | Shared with Copier Memory |
Standard Features | Embedded Scan-to-Email, HDD, Folder, URL, Color Scanning |
File Formats | Single-Page and Multi-Page TIFF, PDF, High Compression PDF, Single-Page JPEG, Single and Multiple page PDF/A |
Fax:
Circuit | PSTN, PBX |
Compatibility | ITU-T G3 |
Resolution | 200 x 200/100 dpi (Standard) 400 x 400 dpi (Optional) |
Compression Method | MH, MR, MMR, JBIG |
Scan Speed | 0.90 seconds 8.5 x 11″ (A4 SEF) |
Modem Speed | 33.6 Kbps with Auto Fallback |
Transmission Speed | G3: 3 seconds per page (MMR Compression) G3: 2 seconds per page (JBIG Compression) |
Memory Capacity (SAF) | 4 MB standard (up to 320 pages) 28 MB maximum (up to 2,240 pages) |
Memory Backup | 1 hour |
Auto Dials | 2,000 with HDD |
Group Dials | 100 (max. 500 numbers per group) |
ID Code Programming | 4 digits |
User Function Key | 3 keys |
Standard Features | Dual Access, Image Rotation, LAN-Fax Capability*, Internet Faxing (T.37)*, IP Faxing (T.38)*, Fax Forwarding to E-mail/HDD/Folder* |
Optional Features | Simultaneous operation of up to 3 lines (G3 x 3) |
Security:
HDD Encryption, HDD Data Overwrite, Quota Limit Setting Optional with Print/Scan: SMTP over SSL, S/MIME, IPsec Communication, Locked Print Password Encryption, Encrypt Address Book, SSL Secure Socket Layer, Windows/LDAP/User Authentication, SNMP v3, Encryption of Password PDF, Encrypted PDF, IP Filtering |
